PARKSIDE® PERFORMANCE cross line laser »PKLLP 360 A1«, with rechargeable battery
From our PARKSIDE PERFORMANCE series
Battery: Li-Ion 4 V (2.6 Ah)
Working range: up to 15 m
Leveling time: approx. 4 s

PARKSIDE® PERFORMANCE cross line laser 360 degrees »PKLLP 360 A1«, with rechargeable battery

properties

360 ° rotation laser with horizontal all-round projection and vertical crossing laser line
Precise, simultaneous marking on all room walls
For the exact placement of wall shelves, wall lights, tiles, strips or pictures
Green laser light with better visibility even in bright areas
(4 x higher light output than comparable devices with red laser)
Versatile due to 2 projection modes:
Self-leveling, vertical alignment with LED status display
Any angle that can be set with the laser pendulum fixed
Automatic flashing when self-leveling when the initial inclination is exceeded
Compact housing with 6.35 mm tripod mount (¼ “) and charging connection
Tripod with extendable central column using a crank and extendable legs (max. Height 1.5 m)
With adjustable swivel head with integrated spirit level

Included accessories:

Tripod, charging cable with USB-C connection (1m)

Compared to the PARKSIDE cross line laser PKLL 8 A3:

up to 4 times better laser line visibility
up to 80% larger work area

PARKSIDE® PERFORMANCE cordless drill »PABSP 20 Li C2«, without battery and charger
From our PARKSIDE PERFORMANCE series
Torque: 60 Nm
Speed: max. 2000 rpm

PARKSIDE® PERFORMANCE cordless screwdriver 20 V »PABSP 20 Li C2«, without battery and charger
properties
Brushless motor – particularly durable, powerful and low-wear
Fast, tool-free change between drilling and screwing functions
2-speed gearbox with infinitely variable speed and quick stop
Magnetic bit holder
Automatic spindle lock SPINDLE LOCK
21 preselectable torque levels and additional drilling settings
Integrated LED work light
Practical belt clip
Röhm drill chuck made of metal with radial locking
Including carrying case
Device compatible with all batteries of the “PARKSIDE X 20 V Team” series
Battery and charger are not included in delivery (sold separately)

Compared to the PARKSIDE 2-speed cordless drill / driver PABS 20-Li D4:
up to 50% higher torque
up to 10 times longer engine life
up to 40% higher drilling speed

PARKSIDE PERFORMANCE cordless hammer drill »PSBSAP 20-Li A1«, without battery and charger
From our PARKSIDE PERFORMANCE series
Torque: max. 80 Nm Impact
frequency: 36000 min-¹

PARKSIDE PERFORMANCE cordless hammer drill »PSBSAP 20-Li A1«, without battery and charger

properties

Brushless motor – particularly long service life due to less wear
Powerful motor with 2-speed gearbox and switchable high-performance hammer mechanism
High quality “Extra 50” Röhm drill chuck made of metal with radial locking (Made in Germany)
On / off switch with stepless speed control and quick stop
Integrated LED work light
Ergonomic soft grip equipment
Including plastic carrying case
Adjustable additional handle with metal depth stop
Right / left rotation
Device compatible with all batteries of the “PARKSIDE X 20 V Team” series
Battery and charger are not included (sold separately)

PARKSIDE PERFORMANCE cordless jigsaw »PSSPA 20-Li A1«, without battery and charger (without battery and charger)
From our PARKSIDE PERFORMANCE series Pendulum stroke levels
: 3 + fine
cut setting Cutting angle: 0 ° / 22.5 ° / 45 °

PARKSIDE cordless jigsaw Performance »PSSPA 20-Li A1«, without battery and charger
properties
Brushless motor – particularly long service life due to less wear
Fast sawing progress and optimal curve maneuverability thanks to 3-stage adjustable pendulum stroke
Fine cut adjustment without pendulum stroke
7-stage adjustable stroke rate: 1 x automatic + 6 selectable stages
5 selectable cutting angles Integrated
LED work light with 2 extended functions: 1.Light before machine start / 2.Afterglow (approx. 10 s)
Quick-release chuck SAW LOCK for easy saw blade changes
Splinter protection
Surface-friendly sliding shoe attachment made of plastic
Chip-free cutting line thanks to the blower function
Connection for external dust extraction
Foldable and removable, transparent saw guard
Ergonomic soft grip equipment
Including carrying case
Accessories included: 1 plastic sliding shoe attachment , 2 wood saw blades (Swiss Made), 1 metal saw blade (Swiss Made), 1 rip fence, 1 Allen key, 1 adapter for external dust extraction

DO YOU STILL NEED A BATTERY OR CHARGER? HERE YOU WILL FIND ALL MATCHING BATTERIES AND CHARGERS FOR YOUR POWERTOOL ➠

Compared to the PARKSIDE cordless pendulum jigsaw PSTDA 20-Li B3:
30% faster work progress
20% longer running time
10 x longer engine life

Parkside Performance Cordless Angle Grinder 20V PWSAP 20-Li C3

AKKU-WINKELSCHLEIFER 20 V / CORDLESS ANGLE GRINDER 20 V / MEULEUSE D’ANGLE SANS FIL 20 V PWSAP 20-Li C3

IAN: 337395

Features
Bare unit – battery and charger are not included
Brushless motor – especially durable and powerful with less wear & tear
Robust die-cast aluminium gear housing with 3-position front handle
Electronically controlled soft-start and quick-stop
Quick tool-free adjustment of the safety guard
With spindle lock for changing disc easily
Suitable for all standard discs up to Ø 125mm (e.g. from Parkside)
Can also be used with wire cup or wire wheel brushes

Technical data
Cordless angle grinder PWSAP 20‑Li C3
Rated voltage: 20 V
Rated speed n: 10000 min–1
Accessory tool diameter: Ø 125 mm
Wheel thickness: max. 8 mm
Spindle thread: M14
Battery pack PAP 20 A3 **
Type: Lithium-Ion
Rated voltage: 20 V max.
Capacity: 4 Ah
Energy value: 72 Wh
Number of cells: 10
Rapid battery charger PLG 20 B1 **
Input:
Rated voltage: 230–240 V∼
Rated frequency: 50 Hz
Rated power: 120 W
Fuse (internal): 3.15 A /
Output:
Rated voltage: 21.5 V
Charging current: 4.5 A
Protection class: II /
Charging time:
Battery type PAP 20 A3, 4.0 Ah
(available separately): 60 minutes
Battery type PAP 20 A1, 2.0 Ah
(available separately): 45 minutes

Parkside Performance Cordless Combi Drill PKHAP 20-Li A1

AKKU-KOMBIHAMMER / CORDLESS COMBI DRILL / PERFORATEUR-BURINEUR SANS FIL PKHAP 20-Li A1

IAN: 337406

Features
Bare unit – battery and charger are not included
Brushless motor – extra long life due to less wear & tear
For powerful drilling and chiselling in concrete, stone, metal or wood
Keyless chuck with receptor as per the SDS-Plus System
Adjusting wheel for speed limitation
Integrated LED work light
Depth stop made from metal
With soft-grip, non-slip elements
Additional handle rotates through 360°

Technical specifications
Cordless combi drill PKHAP 20-Li A1
Rated voltage 20 V (DC)
Idle speed n0
0–950 rpm
Stroke rate 0–4700 rpm
Impact energy 3 J
Max. drill diameter 13 mm for steel
27 mm for wood
24 mm for concrete
IB_337406_PKHAP20LiA1_LB8.indb 16 10.08.20 15:35
Battery PAP 20 A3*
Type LITHIUM ION
Rated voltage 20 V (DC)
Capacity 4 Ah (80 Wh)
Cells 10
High-speed battery charger PLG 20 A3*
INPUT
Rated voltage 230–240 V ~, 50 Hz (AC)
Rated power
consumption 120 W
Fuse (internal) 3.15 A T3.15A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 4.5 A
Charging time approx. 60 min
Protection class II / (double insulation)

BATTERY AND CHARGER ARE NOT INCLUDED

Noise emission value
Noise measurement value determined in accordance with EN 60745. The A-rated noise level of
the power tool is typically as follows
Hammer-drilling
Sound pressure level LpA = 93.6 dB(A)
Uncertainty K = 3 dB
Sound power level LWA = 104 dB(A)
Uncertainty K = 3 dB
Total vibration value
Total vibration values (vector total of three directions) determined in accordance with EN 60745:
Hammer-drilling (main handle)
ah, AG = 5.677 m/s2
, K = 1.5 m/s2
(additional handle)
ah, AG = 6.334 m/s2
, K = 1.5 m/s2

Parkside Performance Cordless Cross Line Laser PKLLP 360 A1

Akku-Kreuzlinienlaser / Cordless Cross Line Laser / Niveau laser en croix sans fi l PKLLP 360 A1

IAN: 346569

Features
360° rotating laser with horizontal all-round projection and a vertically crossing laser line
Precise, simultaneous marking on all room walls
For precise placement of wall shelves, wall lights, tiles, mouldings or pictures
Green beam laser with better visibility, even in bright areas (4x brighter than comparable devices with a red beam laser)
Automatic blinking when self-levelling with exceeded initial incline (±3°)
Tripod with an extendable centre column with crank and extendable legs (max. height 1.5m)
With an adjustable swivel head with integrated spirit level

Technical specifications
Working range ……..15 m*
Weight
(without
tripod) …….approx. 350 g
Operating voltage
Umax …………………4 V
Nominal capacity …2,6 Ah
Charging voltage
UIN ………………….5 V
Charging current ……… 1 A
Self-levelling range ….. ± 3°
Levelling
accuracy ………. ± 4 mm/m
Laser
Wavelength …510-530 nm
Laser class ……………….. 2
Levelling time ………..approx. 4 sec.

Parkside Performance Cordless Drill 20V PABSP 20-Li C2

IAN: 337401

Features
Bare unit – battery and charger are not included
Brushless motor – especially durable, powerful with less wear & tear
Fast, tool-free changeover between drill and screw functions
2 speed gearbox with adjustable rotation speed and quick stop
Magnetic bit holder
Automatic SPINDLE LOCK spindle restraint
21 pre-selectable torque settings and additional drill setting
Integrated LED work light
Practical belt clip
Röhm drill chuck made from metal with radial locking

Scope of delivery
mWARNING!
u The product and the packaging are not
children’s toys! Children must not play with
plastic bags, sheets and small parts! There
is a danger of choking and suffocation!
1x Cordless drill 20 V PABSP 20-Li C2
1x Battery pack PAP 20 A1 *
1x Rapid battery charger PLG 20 B1 *
1x Carrying case
1x Instruction manual
Parts description
Figure A:
[1] Chuck
[2] Chuck ring
[3] Torque sleeve
[4] Gear selector
[5] Rotation direction switch/lock
[6] On/off switch/speed control
[7] Grip handle
[8] Bit holder (magnetic)
[9] Belt clip
[10] Battery pack *
[11] LED work light
Figure B:
[10] Battery pack *
[12] Release button for battery pack
[13] button (charging level)
[14] Charging level LEDs (red/orange/green)
Figure C:
[15] Battery charger (rapid battery charger) *
[16] Power cord with power plug
[17] Charging control LED – Green
[18] Charging control LED – Red
Not illustrated:
[19] Carrying case
Technical data
Cordless drill PABSP 20‑Li C2
Rated voltage: 20 V
Drill chuck type: keyless chuck
Gearbox: 2 speed
No-load speed n0:
1st gear: 0 – 500 min-1
2nd gear: 0 – 2000 min-1
Max. torque: 60 N m
Chuck clamping range: max. Ø 13 mm
Max. drill diameter: into steel Ø 13 mm
into wood Ø 38 mm
Battery pack PAP 20 A1 *
Type: Lithium-Ion
Rated voltage: 20 V max.
Capacity: 2 Ah
Energy value: 36 Wh
Number of cells: 5
Rapid battery charger PLG 20 B1 *
Input:
Rated voltage: 230–240 V~ Rated frequency: 50 Hz
Rated power: 120 W
Fuse (internal): 3.15 A /
Output:
Rated voltage: 21.5 V
Charging current: 4.5 A
Protection class: II /

Battery and rapid battery charger are not
included
Charging time:
Battery type PAP 20 A1, 2.0 Ah
(available separately): 45 minutes
Battery type PAP 20 A3, 4.0 Ah
(available separately): 60 minutes
8 GB/CY
Recommended ambient temperature:
While charging: +4 to +40 °C
During operation: +4 to +40 °C
During storage: +20 to +26 °C
Noise emission value
The measured values have been determined in
accordance with EN 62841. The A-rated noise
level of the power tool is typically as follows:
Sound pressure level LpA: 79.1 dB(A)
Uncertainty KpA: 3 dB
Sound power level LWA: 90.1 dB(A)
Uncertainty KWA: 3 dB
Vibration emission value
Vibration total values (triaxial vector sum)
determined according to EN 62841:
Drilling into metal:
Hand/arm vibration ah,D: < 2.5 m/s2
(1,27 m/s2)
Uncertainty K: 1.5 m/s2

Parkside Performance Cordless Jigsaw / PSSPA 20-Li A1 / Bare unit – battery and charger are not included

Akku-Stichsäge / Cordless Jigsaw / Scie sauteuse sans fi l PSSPA 20-Li A1

IAN: 329790

Features
Keyless chuck SAW LOCK for easy blade exchange
Dust-free cutting line thanks to the blower function
Connection to external dust extractor – includes adaptor
Hinged and removable, transparent saw protection
Anti-splinter guard
Ergonomic soft grip fittings
Slide shoe with surface-friendly plastic cover

Technical data
Cordless Jigsaw …. PSSPA 20-Li A1
Nominal input voltage U ………….. 20 V
Idle speed n0 ………………….0 – 3800 rpm
Saw stroke …………………………….26 mm
Cutting depth in wood …………………….max. 135 mm
in non-ferrous metal ……….max. 20 mm
in steel (soft) …………………max. 10 mm
Weight (without battery)….Approx. 1.5 kg
Sound pressure level (LpA) ……………….74,3 dB(A), KpA= 3 dB
Sound power level (LWA) …………….. 85,3 dB(A), KWA= 3 dB
Vibration (ah ) ……. 4,02 m/s2 ;K= 1,5 m/s2
Temperature…………………….. max. 50 °C
Charging process ……………….4 – 40 °C
Operation ……………………..-20 – 50 °C
Storage ……………………………0 – 45 °C

Parkside Performance Cordless Drill 20V PABSP 20-Li C2

IAN: 337401

Features
Bare unit – battery and charger are not included
Brushless motor – especially durable, powerful with less wear & tear
Fast, tool-free changeover between drill and screw functions
2 speed gearbox with adjustable rotation speed and quick stop
Magnetic bit holder
Automatic SPINDLE LOCK spindle restraint
21 pre-selectable torque settings and additional drill setting
Integrated LED work light
Practical belt clip
Röhm drill chuck made from metal with radial locking

Scope of delivery
1x Cordless drill 20 V PABSP 20-Li C2
1x Battery pack PAP 20 A1 *
1x Rapid battery charger PLG 20 B1 *
1x Carrying case
1x Instruction manual
Parts description
Figure A:
[1] Chuck
[2] Chuck ring
[3] Torque sleeve
[4] Gear selector
[5] Rotation direction switch/lock
[6] On/off switch/speed control
[7] Grip handle
[8] Bit holder (magnetic)
[9] Belt clip
[10] Battery pack *
[11] LED work light
Figure B:
[10] Battery pack *
[12] Release button for battery pack
[13] button (charging level)
[14] Charging level LEDs (red/orange/green)
Figure C:
[15] Battery charger (rapid battery charger) *
[16] Power cord with power plug
[17] Charging control LED – Green
[18] Charging control LED – Red
Not illustrated:
[19] Carrying case
Technical data
Cordless drill PABSP 20‑Li C2
Rated voltage: 20 V
Drill chuck type: keyless chuck
Gearbox: 2 speed
No-load speed n0:
1st gear: 0 – 500 min-1
2nd gear: 0 – 2000 min-1
Max. torque: 60 N m
Chuck clamping range: max. Ø 13 mm
Max. drill diameter: into steel Ø 13 mm
into wood Ø 38 mm
Battery pack PAP 20 A1 *
Type: Lithium-Ion
Rated voltage: 20 V max.
Capacity: 2 Ah
Energy value: 36 Wh
Number of cells: 5
Rapid battery charger PLG 20 B1 *
Input:
Rated voltage: 230–240 V~ Rated frequency: 50 Hz
Rated power: 120 W
Fuse (internal): 3.15 A /
Output:
Rated voltage: 21.5 V
Charging current: 4.5 A
Protection class: II /

Battery and rapid battery charger are not
included
Charging time:
Battery type PAP 20 A1, 2.0 Ah
(available separately): 45 minutes
Battery type PAP 20 A3, 4.0 Ah
(available separately): 60 minutes

Recommended ambient temperature:
While charging: +4 to +40 °C
During operation: +4 to +40 °C
During storage: +20 to +26 °C
Noise emission value
The measured values have been determined in
accordance with EN 62841. The A-rated noise
level of the power tool is typically as follows:
Sound pressure level LpA: 79.1 dB(A)
Uncertainty KpA: 3 dB
Sound power level LWA: 90.1 dB(A)
Uncertainty KWA: 3 dB
Vibration emission value
Vibration total values (triaxial vector sum)
determined according to EN 62841:
Drilling into metal:
Hand/arm vibration ah,D: < 2.5 m/s2
(1,27 m/s2)
Uncertainty K: 1.5 m/s2
