Brand Name
Parkside
EAN
- 4019641031126
IAN
96266
Product description
- 2-in-1 function: rotatable handle for hard-to-reach areas
- LED workpiece lighting
- Hexagon bit collet with automatic locking mechanism
- Integrated battery charge level indicator
- Ergonomic Soft Grip
Features
ON/OFF switch
Rotation direction switch/safety lock-out
LED
Tool holder
Locking collar
Torque setting
Battery level display
Locking button
Charging socket (appliance)
Charger
Package contents
1 cordless screwdriver PASS 3.6 B2
1 charger PASS 3.6 B2-2
1 carrying case
24 bits x 25 mm
2 bits x 50 mm
1 bit extension
1 operating instructions
Technical details
Cordless screwdriver: PASS 3.6 B2
Rated voltage: 3.6 V
Battery (integrated): LITHIUM-ion
Battery capacity: 1500 mAh
Nominal idle speed: n0 = 200 min-1
Torque: max. 4.0 Nm
Tool holder: 6.35 mm (¼”)
Charger: PASS 3.6 B2-2
INPUT:
Rated voltage: 230 – 240 V∼ 50/60 Hz
Rated current: 200 mA
OUTPUT:
Rated voltage: 5.5 V
Rated current: 600 mA
Charging time: approx. 3 hours
Protection class: II /
Noise and vibration data:
Noise measurement determined in accordance
with EN 60745 The A-rated noise level of the
power tool is typically:
Sound pressure level: 57 dB(A)
Sound power level: 68 dB(A)
Uncertainty K: 3 dB
Vibration values (vector total of three directions)
determined in accordance with EN 60745
Screws: Vibration emission value ah = 0.393 m/s2
Uncertainty K = 1.5 m/s2
