IAN: 346464

Product description
Fits all commercially available 1/2 “(13 mm) embedded systems
4-way splitter:
4 continuously adjustable outputs with connections
in set with tap connector for threads 33.3 and 26.5 mm (G 1 “, G ¾”)
two-way valve, 6 elements:
2 flexible 13 mm (½ “) hose connections prevent bending and rotating – 1 of them with water retention
13 mm (½ “) garden hose repair element
two-way valve for tap connection for threads 33.3 and 26.5 mm (G 1 “, G ¾”)
1 tap connector for threads 33.3 and 26.5 mm (G 1 “, G ¾”)
1 hose extension connection
Y-shaped connector, 6 elements:
3 x 13 mm hose connections (½ “)
1 Y-Hose Clutch
1 tap connector for threads 33.3 and 26.5 mm (G 1 “, G ¾”)
1 hose extension connection
irrigation set, 5 elements:
1 tap connector for threads 33.3 and 26.5 mm (G 1 “, G ¾”)
2 hose connections 13 mm (½ “)
1 hose connection 13 mm (½ “) with water retention
1 spray nozzle, adjustable
Technical parameters
operating pressure: 4 bar
Dimensions
4-way distributor: approx. 6.5 x 10.2 x 17.6 cm (W x H x L)
two-way valve, 6 elements:
tap connection for threads: approx.3.9 cm x 4.8 (L) cm (Ø x L)
Hose connection: approx.3.6 cm x 10.9 cm (Ø x L)
hose coupling: approx.3.1 x 5.0 cm (Ø x L)
hose repair piece: approx.3.6 x 7.2 cm (Ø x L)
thread for the two-way valve: approx. 11 x 9.5 x 4 cm (L x H x D)
Y-shaped connector, 6 elements:
tap connection for threads: approx.4.1 x 4.9 cm (Ø x L)
hose coupling: approx.3.1 x 5 cm (Ø x L)
tap connection for threads: approx.3.4 x 5.7 cm (Ø x L)
Y-shaped clutch: approx. 6.7 x 2 x 6.7 cm (Ø x H x L)
irrigation set, 5 elements:
tap connection for threads: approx.4.1 x 4.9 cm (Ø x L)
tap connection for threads: approx.3.4 x 5.7 cm (Ø x L)
spray nozzle, adjustable: approx.3.3 x 13.4 cm (Ø x L)
Material of execution
Plastic
Weight
four-way valve: approx. 210 g
two-way valve, 6 elements: approx. 245 g
Y-shaped connector, 6 elements: approx. 129 g
irrigation set, 5 elements: approx. 152 g
