Tag: hose

Posted on

PARKSIDE® garden hose »Flexi«, 15 m, twist-free
Nominal pressure: 4.5 bar

PARKSIDE® garden hose Flexi, 15 m
properties
Expands up to 15 m at water pressure of approx. 5.5 m
Self-draining after use, contracts again
Light, twist-free and kink-resistant
Can be stowed away to save space
Suitable for taps 26.5 mm (G ¾ “) and 21 mm (G ½”) as well as for standard hose connector systems
Weather and UV resistant
Included accessories: connection set with 2 plug connections, 1 tap connector, 1 plug connection adapter, 1 regulating stop, 3 replacement sealing rings

Technical specifications
Nominal pressure: 4.5 bar

material
Outer tube: polyester
Inner hose, plug connections, regulating stop, tap connector, plug connection adapter: plastic
Seals: rubber
Dimensions
Filled: approx. Ø 1.7 cm x L 15 m
Unfilled: approx. L 5.5 m
weight
Hose (without accessories): approx. 527 g
Accessories: approx. 3.5 g

Posted on

PARKSIDE® spray hose 20 m / bead hose 15 m
Temperature resistant: -10 to 50 ° C

PARKSIDE® spray hose 20 m / bead hose 15 m
properties
Suitable for all common 13 mm quick connector systems (½)
Spray hose:
For flexible and comfortable garden irrigation
3-channel system evenly distributed over the entire length
Including 1 quick connector and 1 end piece
Weather, UV and temperature resistant (-10 ° C to + 50 ° C)
The hose can be used and stored in this outside temperature range
Bead tube:
For gentle surface and subsurface irrigation
Can be laid down to a depth of 0.5 m
Weather, UV and temperature resistant (-10 to +50 ° C)
Can be shortened individually
Including 1 quick connector with pressure reducer and 1 sealing cap
Technical specifications
Spray hose: Operating pressure: min. 2 bar – max. 4 bar
Soaking hose: Operating pressure: min. 1 bar to max. 3 bar
material
Plastic, rubber

Dimensions
Spray hose
Length: approx. 20 m
wrapped: approx. W 400 x D 400 x H 33 mm
Bubble tube
Length: approx. 15 m
wrapped: approx. W 380 x D 380 x H 70 mm
weight
Spray hose: approx. 1540 g
Pearl tube: approx. 1500 g

Posted on

PARKSIDE garden hose 30 m, 5-ply
Complete set with hose, syringe and connections
Hose length: approx. 30 m
Ø hose: approx. 13 mm (½)
High pressure resistance (bursting pressure approx. 27 bar)
Weather, UV and temperature resistant ( -10 to +60 ° C)

PARKSIDE garden hose 30m, 5-ply
properties
Complete set with hose, syringe and connections
1 permanently elastic and dimensionally stable garden hose with cross fabric reinforcement
1 infinitely adjustable regulating syringe
2 pieces of hose and 1 piece of water stop hose
1 tap piece for connections with 26.44 mm thread (G¾ “)
Made of high quality material (first choice PVC)
High pressure resistance (bursting pressure approx. 27 bar)
Weather, UV and temperature resistant (-10 to +60 ° C)
Scope of delivery: 1 hose, 1 regulating syringe, 2 hose pieces, 1 tap piece
Technical specifications
Hose length: approx. 30 m
Ø hose: approx. 13 mm (½)
Max. Operating pressure: 6 bar
material
plastic

Dimensions
approx. 380 x 380 x 90 mm

Weight
approx. 135 g / m

Hints
Not suitable for drinking water

Posted on

PARKSIDE garden hose »Flexi«, 15 m, twist-free
Nominal pressure: 4.5 bar

PARKSIDE garden hose Flexi, 15 m
properties
Expands up to 15 m at water pressure of approx. 5.5 m
Self-draining after use, contracts again
Light, twist-free and kink-resistant
Can be stowed away to save space
Suitable for taps 26.5 mm (G ¾ “) and 21 mm (G ½”) as well as for standard hose connector systems
Weather and UV resistant
Included accessories: connection set with 2 plug connections, 1 tap connector, 1 plug connection adapter, 1 regulating stop, 3 replacement sealing rings

Technical specifications
Nominal pressure: 4.5 bar

material
Outer tube: polyester
Inner hose, plug connections, regulating stop, tap connector, plug connection adapter: plastic
Seals: rubber
Dimensions
Filled: approx. Ø 1.7 cm x L 15 m
Unfilled: approx. L 5.5 m
Weight
Hose (without accessories): approx. 527 g
Accessories: approx. 3.5 g

Posted on

Parkside Wall-Mounted Hose Reel / PSA 15 A1

WAND-SCHLAUCHAUFROLLER/WALL-MOUNTED HOSE REEL / ENROULEUR DE TUYAU MURAL PSA 15 A1
Manual

IAN: 360680

Features
Wall-Mounted Hose Reel
PSA 15 A1
Swivelling hose box with holder for wall mounting
Stop function keeps the extendable hose at the required length
Convenient automatic gentle retraction

Parts description/
Scope of delivery
1 1 wall bracket
2 1 carrying handle
3 1 hose box
4 1 limit stop
5 1 irrigation hose
6 1 hose connector with water stop for spray
nozzle
7 1 spray nozzle
8 4 wall plugs (6 x 40mm)
9 1 split pin
10 4 screws (6 x 50mm)
11 1 connection hose
12 1 hose connector for tap

Posted on

PARKSIDE hose reel, 15 m length
Swivel range: 180 °
Temperature resistance: -20 to 60 ° C

PARKSIDE hose reel, 15 m length
properties
Swiveling hose box with holder for wall mounting
The locking function keeps the easily extendable hose in the desired length
Convenient automatic roll-up with soft retraction
Twist-proof garden hose with fabric reinforcement
Garden sprayer with flow control
Suitable for all common 12.7 mm hose connector systems (½ “)
With a practical handle
Weather and UV resistant
Including mounting material for wall mounting
Included accessories: 1 garden
sprayer , 1 piece of hose (½ “• 12.7 mm), 1 piece of hose with water stop (½” • 12.7 mm), 1 tap piece with reduction (1 “• 33.3 mm / ¾” • 26, 5 mm)

Technical specifications
Hose box system: pull-out lock and automatic roll-up
Wall bracket swivel range: 180 °
Temperature resistance: -20 to 60 ° C
Max. Operating pressure (hose / fittings): 10 bar / 8 bar
Burst pressure (hose / fittings): 30 bar / 12 bar
material
Plastic, fiberglass

Dimensions
Total: approx. W 19 x H 33 x L 38 cm
Garden hose: approx. L 15 m
Supply hose: approx. 1 m long
Weight
approx. 5.2 kg

Posted on

PARKSIDE compressed air hose reel, for all compressed air devices with standard coupling
Operating pressure: max. 16 bar (at 23 ° C) / max. 11 bar (at 60 ° C)

PARKSIDE hose reel compressed air with bracket frame
properties
Suitable for all common compressed air devices with standard coupling
High quality compressed air hose
Plug-in nozzle and one-hand quick-release coupling made of brass
Bracket frame made of powder-coated tubular steel with hose guide
Increased stability through reinforced drum discs
Technical specifications
Operating pressure: max. 16 bar (at 23 ° C) / max. 11 bar (at 60 ° C)
material
Drum: polypropylene (PP)
Hose: polyvinyl chloride (PVC) with fabric insert
Fittings: brass
Frame: steel, powder-coated
Dimensions
Overall: approx. 22 x 27.5 x 34 cm
Hose outside / inside: approx. Ø 11.3 / 6.3 mm
Hose length: approx. 20 m
Weight
approx. 3.1 kg

Posted on

PARKSIDE compressed air hose reel / compressed air maintenance unit
Hose reel / maintenance unit with pressure reducer, water separator and mist oiler
With device for wall mounting

PARKSIDE compressed air hose reel
properties
Hose reel with retraction:
Convenient hose reel with automatic feed
180 ° swiveling drum housing with robust metal wall bracket
Durable hose design in kink-resistant quality
10 m compressed air hose including quick connector (¼ “)
3 m compressor connection hose with connection piece (¼ “)
Fixation of the pulled out hose by finely divided locking
Automatic winding by pulling briefly on the hose
For wall mounting or hanging with an integrated snap hook
Including wall mounting material
Hose reel can be removed from the wall bracket without tools
Maintenance unit:
3 in 1: pressure regulation, compressed air preparation and lubrication
Pressure reducer with continuously adjustable operating pressure and control manometer
Water separator with exchangeable filter and integrated drain valve
Mist lubricator with adjustable oil supply and opening for refilling
Including pre-assembled connection adapter
Container can be removed with a screw cap without tools
With device for wall mounting
Technical specifications
Hose reel:
Roll-up system: automatic
Max. Working pressure: 10 bar
Compressed air connection size: ¼ “
Maintenance unit:
Adjustable operating pressure: 0.5–8 bar
Connection thread: ¼ “
Air treatment: replaceable filter + water separator
Lubrication: adjustable mist lubricator
Max. Working pressure: 8 bar
material
Connections: steel

Dimensions
Hose reel with retraction:
Overall: approx. 252 x 234 x 101 mm
Compressed air hose: approx. L 10 m
Compressor connection hose: approx. L 3 m
Maintenance unit: approx. 220 x 220 x 100 mm
Weight
Hose reel with retraction function: approx. 1,700 g
Maintenance unit: approx. 750 g

Posted on

PARKSIDE compressed air hose »PDS 10 A2«, with plug-in socket
Working pressure: max. 16 bar (at 23 ° C)
Length: 10 m
Suitable for all common compressed air devices with standard
coupling. High quality compressed air hose with fabric insert

PARKSIDE compressed air hose 10 m »PDS 10 A2«
properties
Suitable for all common compressed air devices with standard coupling
High quality compressed air hose with fabric insert
Plug-in nozzle and one-hand quick-release coupling made of brass
Connection of several hoses possible
Technical specifications
Working pressure: max. 16 bar (at 23 ° C), max. 11 bar (at 60 ° C)

material
Press sleeve: brass

Dimensions
Length: approx. 10 m
Ø hose (outside / inside): approx. 11.3 mm / approx. 6.3 mm
Weight
approx. 1 kg

Posted on

MIOMARE shower hose, with rotating cone, made of stainless steel
Dimensions: approx. L 1.5 m
Suitable for: all standard G 1/2 “connections
With rotating cone: practical protection against twisting of the hose

MIOMARE shower hose with rotating cone
properties
Extendable up to 2 m in length for great freedom of movement
Ideal for bathtub and shower
With rotating cone: practical protection against twisting of the hose
With high quality stainless steel coating
Suitable for all standard G 1/2 “connections (outer diameter approx. 21 mm)
Including 2 seals
material
stainless steel

Dimensions
approx L 1.5 m

Weight
approx. 220 g
